1 1 INDEX 4
8 Locknuts, lockwashers, lockplates
Locknuts, lockwashers, lockplates
AN and ANL series Locknuts 167
AW series Lockwashers 168
AWL series Lockwashers 169
AL and ALL series Lockplates 170
9 Technical information
Bearing selection
Selection procedure 171
External self aligning ball bearing units
Construction overview 172
Installation - Set screw method 173
Installation - Eccentric collar method, Adapter sleeve method 174
Installation - Covered bearing unit 175
Shaft designs 177
Grease & Operating temperature 178
Service life of grease 179
Radial internal clearances 180
Internal self aligning ball and roller bearing units
Overview - Spherical roller, self aligning ball bearings 181
Basic load rating and life 182
Tolerances 185
Internal clearance 187
Shaft and housing fits 189
Handling of bearings 190
Limiting speed and lubrication 194
Strength of plummer block housings 196
Grease fill and shaft information 197
Shaft and housing tolerance charts 198
Conversion tables
Shaft diameter to RPM 200
Inches to mm 200
