Page 265 - needle bearings

Cam followers stud type truck rollers
NTN

Type CRVʝXLL Type CRVʝH
(Full-complement roller and sealed type) (with hexagon hole)

Basic load ratings Load ratings of truck Limiting speeds Maximum Bearing numbers Mass
dynamic static dynamic static tightening (approx.)
torque
N kgf N kgf r/min kg
Spherical Cylindrical Spherical Cylindrical grease oil Nŋm kgfŋm Type Type Type
Cr Cor Cr Cor outer ring outer ring outer ring outer ring CRVʝʝX 1) CRVʝʝXLL 1) CRVʝX
3 400 3 750 350 385 2 090 790 213 81 ˞17 000 ˞22 000 2 0.2 CRV8X CRV8XLL 0.010
3 950 4 550 405 465 2 310 790 235 81 ˞17 000 ˞22 000 2 0.2 CRV8-1X CRV8-1XLL 0.011
5 550 7 600 565 770 3 000 1 080 310 110 ˞12 000 ˞15 000 4 0.4 CRV10X CRV10XLL 0.020
6 200 8 700 630 885 3 300 1 080 335 110 ˞12 000 ˞15 000 4 0.4 CRV10-1X CRV10-1XLL 0.022
8 050 13 300 825 1 360 4 600 1 380 470 140 9 000 ˞11 000 13 1.3 CRV12X CRV12XLL 0.038

8 050 13 300 825 1 360 5 350 1 710 545 174 9 000 ˞11 000 13 1.3 CRV14X CRV14XLL 0.048
11 700 18 900 1 190 1 920 7 400 2 060 755 210 7 100 9 200 18 1.9 CRV16X CRV16XLL 0.080
11 700 18 900 1 190 1 920 8 350 2 430 850 248 7 100 9 200 18 1.9 CRV18X CRV18XLL 0.096
17 700 35 000 1 810 3 600 11 400 2 840 1 160 290 5 400 7 000 24 2.4 CRV20X CRV20XLL 0.140

17 700 35 000 1 810 3 600 12 500 3 250 1 280 330 5 400 7 000 24 2.4 CRV22X CRV22XLL 0.165
21 100 45 500 2 150 4 650 16 300 3 600 1 660 365 4 800 6 200 51 5.2 CRV24X CRV24XLL 0.240
21 100 45 500 2 150 4 650 17 600 4 050 1 800 410 4 800 6 200 51 5.2 CRV26X CRV26XLL 0.280
28 400 60 500 2 900 6 150 21 600 4 400 2 200 450 4 100 5 300 92 9.3 CRV28X CRV28XLL 0.400

28 400 60 500 2 900 6 150 23 200 4 850 2 360 495 4 100 5 300 92 9.3 CRV30X CRV30XLL 0.440
41 000 87 500 4 200 8 950 31 000 5 300 3 150 540 3 700 4 800 150 15 CRV32X CRV32XLL 0.650
41 000 87 500 4 200 8 950 35 000 6 200 3 550 635 3 700 4 800 150 15 CRV36X CRV36XLL 0.780
54 500 119 000 5 600 12 200 44 500 7 200 4 550 735 3 200 4 100 230 23 CRV40X CRV40XLL 1.20

54 500 119 000 5 600 12 200 49 000 8 250 5 000 840 3 200 4 100 230 23 CRV44X CRV44XLL 1.34
76 500 177 000 7 800 18 000 64 000 9 150 6 500 935 2 700 3 500 435 45 CRV48X CRV48XLL 1.92
76 500 177 000 7 800 18 000 69 000 10 000 7 050 1 020 2 700 3 500 435 45 CRV52X CRV52XLL 2.20
84 500 214 000 8 650 21 800 86 500 11 100 8 800 1 130 2 200 2 800 580 60 CRV56X CRV56XLL 2.92

106 000 244 000 10 800 24 900 113 000 13 200 11 500 1 350 2 200 2 800 760 78 CRV64X CRV64XLL 4.32
189 000 520 000 19 300 53 000 165 000 17 900 16 900 1 830 1 500 1 900 1 820 190 CRV80X CRV80XLL 8.80
260 000 675 000 26 500 68 500 240 000 22 100 24 400 2 250 1 200 1 500 3 550 360 CRV96X CRV96XLL 15.3

Note 2) Grease replenishing hole is provided at front side only (on left side-face in the above sketch). However, in the case with "hexagon hole" no grease
replenishing hole is provided.
Remarks: For the cam follower with ˞marked seal, the allowable running speed is approximately 10 000 r/min.
