KAROSERIE - KAROSSERIE - BODY - CAROSSERIE - CAROSERIA
          312a                                                                                            312a
           1     2     3       4                            5                         6               7
          312a  189      9   16.312.080 Pás zadní úplný - Vollst . Hintere Band - Rear band assy - Bande arriére  1
                                     complet - Banda trasera completa
          312a  189     10   16.312.060 Držák zadní - Hintere Halter - Rear holder - Support arriére - Soporte trasero  1
          312a  189     11   16.312.921 Nádrž paliva kompletní - Vollst. Kraftstoffbehälter - Fuel tank assy - Réservoir  1  180 litrů
                                     de combustible complete - Tanque de combustible completo
          312a  189     12   53.312.916 Zátka - Stopfen - Plug - Bouchon - Tapón        1  M 16x1,5
          312a  189     13   16.312.903 Plovákové zařízení - Kraftstoffvorratszeigerschwimmer - Float type fuel level  1
                                     device - Dispositif d'indication du niveau de carburant par flotteur - Dispositivo
                                     flotador de indicación del nivel del carburante
          312a  189     14   53.312.904 Uzávěr nádrže - Behalterverschluss - Fuel tank filler cap - Fermeture de  1
                                     reservoir - Cierre del tanque
          312a  189    14a   16.312.905 Nádrž paliva - Kraftstoffbehälter - Fuel tank - Réservoir de combustible - Tanque  1  180 litrů
                                     de combustible
          312a  189     15   5511-5730 Knoflík - Knopf - Button - Bouton - Butón        2
          312a  189     16   53.800.002 Hadicová spona - Schlauchband - Hose clip - Collier du tuyau - Abrazadera de  2
                                     la manguera
          312a  189     17   6011-5219 Děrovaná páska - Perforiertesband - Punched band - Bande perforée - Banda  1
                                     perforada
          312a  189     18     99-1366 Šroub - Schraube - Bolt - Vis - Tornillo         2  M 10x16 ČSN 02 1103.55
          312a  189     19     99-1367 Šroub - Schraube - Bolt - Vis - Tornillo         2  M 10x20 ČSN 02 1103.55
          312a  189     20     99-3511 Matice - Mutter - Nut - Ecrou - Tuerca           4  M 10 ISO 4032
          312a  189     21     99-4165 Matice - Mutter - Nut - Ecrou - Tuerca           2  M 10 ČSN 02 1492.25
          312a  189     22     99-4441 Podložka - Unterlegscheibe - Washer - Rondelle - Arandela  4  10,5 ČSN 02 1702.19
          312a  189     23     99-4507 Podložka - Unterlegscheibe - Washer - Rondelle - Arandela  4  10 ČSN 02 1740.09
          312a  189     24     97-4714 Kroužek - Ring - Ring - Anneau - Anillo          1  15x2,65
          312a  189     25   16.312.039 Přípojka - Anschlusstück - Connector - Raccord - Racor  1
          312a  189     26   17.009.917 Kroužek - Ring - Ring - Anneau - Anillo         1
          312a  189     27   16.312.130 Pás přední - Vordere Band - Front band - Bande avant - Banda delantera  1
          312a  189     28   16.312.040 Pás zadní - Hintere Band - Rear band - Bande arriére - Banda trasera  1
















































                                                           277
