Page 167 - needle bearings

Machined ring needle roller bearings, separable Type
NTN

Abutment Mass
dimensions
mm kg
db Da Db ras
max max (approx.)
47.2 53 40.6 0.3 0.275

49.2 53 45.6 0.3 0.083
49.2 53 45.6 0.3 0.165
52.2 60 45.6 0.3 0.175
52.2 60 45.6 0.3 0.377
54.2 60 50.6 0.3 0.140
54.2 60 50.6 0.3 0.295
57.2 63 50.6 0.3 0.168
57.2 61 50.6 0.6 0.355

59.4 64 55.8 0.6 0.166
62.4 64 55.8 0.6 0.200
59.4 64 55.8 0.6 0.310
62.4 68 55.8 0.6 0.216
62.4 68 55.8 0.6 0.425
67.2 70 60.8 1 0.461
67.2 73 60.8 1 0.255
67.2 73 60.8 1 0.500

72.2 80 66 1 0.464
72.2 80 66 1 0.951

77.2 85 71 1 0.499
77.2 85 71 1 1.00

82.2 90 76 1 0.520
82.2 90 76 1 1.04

85.2 90 81 1 0.405
87.2 90 81 1 0.755
87.2 95 81 1 0.580
87.2 95 81 1 1.10
92.2 100 86 1 0.459
