Calculation of Bearing Loads
                                                                                                              NTN







           3.1.2  Loads acting on chain and belt shafts             where
             In the case of power transmission by a chain and a       K ɿActual load acting on shaft  N(kgf)
           belt, the load acting tangentially on the sprocket or the  Kc ɿTheoretically calculated value N (kgf)
           pulley can be determined by formula (3.7).                 fw ɿLoad factor (Table 3.4)

                                      6
                        6
                 19.1ʷ10 ɾHP    1.95ʷ10 ɾHP                       Table 3.4  Load factor fw
                             ʢ
                                            ʣ
             Ktʹʕʕʕʕʕʕʕʕʕ ʕʕʕʕʕʕʕʕʕ ʜʜʜʜʜʜ(3.7)
                    Dpɾn           Dpɾn
                                                                  Extent of shock  fw           Application
             where,                                                                  Electrical machines, machine tools,
                                                                  Nearly no shock 1.0ʙ1.2
               Kt ɿTangential load acting on sprocket or pulley  N (kgf)             measuring instruments
                                                                                     Railway vehicles, automobiles,
               HPɿTransmission power  kW                                             rolling mills, metal working machines,
                                                                                     paper making machines, rubber mixing
               Dp ɿPitch circle diameter of sprocket or pulley  mm  Light shock   1.2ʙ1.5  machines, printing machines, aircraft,
                                                                                     textile machines, electrical units,
                                                                                     office equipment
             In the case of belt driving, initial tension is applied to
           the belt so the pulley and the belt are both always     Heavy shock  1.5ʙ3.0  Crushers, agricultural machines,
                                                                                     construction machines, cranes
           pressed down with a proper load.
                             F1Slackening side
                                                                  3.2  Load distribution to bearings
                         Dp                                         Any loads acting on shafts are distributed to the
                                  Kr                              bearings considering static tension to be supported with
                                                                  the bearings.
                                                                    For example, the loads acting on the bearings in the
                             F2 Tension side
                                                                  gear shaft illustrated in Fig. 3.7 can be expressed in
                       Fig. 3.6  Loads acting on chain/ belt      formulas (3.10) and (3.11).

                                                                            b              c           Dp
             Considering this initial tension, radial load acting on the  FrAʹKr!ʕʕʵKr@ʕʕʵKaʕʕʜʜʜʜʜʜʜʜ(3.10)
           pulley is expressed in formula (3.8).                            l               l            2l
             In the case of chain driving, the radial load acting
           thereon can be expressed using the same formula, if
                                                                            a             aʴbʴc         Dp
           vibration and shock are taken into consideration.        FrBʹKr!ʕʕʴKr@ʕʕʕʕʕʕʴKaʕʕ ʜʜʜʜʜ(3.11)
                                                                            l                    l               2l
             Krʹf bɾKt ʜʜʜʜʜʜʜʜʜʜʜʜʜʜʜʜʜ(3.8)
                                                                   where,
             where,                                                  FrA ɿRadial load acting on bearing-A  N (kgf)
                                                                     FrB ɿRadial load acting on bearing-B  N (kgf)
               KrɿRadial load acting on sprocket or pulley  N (kgf)
                                                                     Kr1ɿRadial load acting on gear-! N (kgf)
               f bɿChain/belt factor (Table 3.3)                     Ka ɿAxial load acting on gear-! N (kgf)
                                                                     Kr2ɿAxial load acting on gear-!! N (kgf)
           Table 3.3  Chain/belt factor f b                          Dp ɿPitch circle diameter of gear-! mm
              Type of chain / belt        f b                        l  ɿBearing to bearing distance  mm
              Chain (single row type)    1.2ʙ1.5
              Vee-belt                   1.5ʙ2.0
              Timing belt                1.1ʙ1.3
                                                                                                       Gear-!!
              Flat belt (with tension pulley)  2.5ʙ3.0                                  l
                                                                                      Gear-!
              Flat belt                  3.0ʙ4.0
                                                                                          Ka
                                                                                      Kr!               Kr@
                                                                                 Dp
                                                                           FrA                   FrB
           3.1.3  Load factor
             In an actual machine, the shaft load is mostly greater    Bearing-A             Bearing-B
           than the theoretically calculated load due to vibration,
           shock, etc. The load acting on the shafts of a machine                 a           b        c
           can be determined by formula (3.9).
             Kʹ fWɾKC ʜʜʜʜʜʜʜʜʜʜʜʜʜʜʜʜʜ(3.9)                                       Fig. 3.7  Gear shaft
