Solid type linear ball bearings
NTN

Type KLM Type KLMʝʝLL
Type KLMʝʝS Type KLMʝʝSLL
Type KLMʝʝP Type KLMʝʝPLL

With seal

FW 3ʙ35mm

Boundary dimensions Basic load ratings Bearing Number Mass
dynamic static dynamic static numbers of
ball
mm N kgf rows kg
Fw D C C1 C2 D1 g h В
ʶ0.240 Cr Cor Cr Cor (approx.)
3 0 7 0 10 0 ʵ ʵ ʵ ʵ ʵ ʵ 51 40 5 4 KLM03 4 0.002
ʵ0.008 ʵ0.010 ʵ0.120
0 0 0
4 8 12 ʵ ʵ ʵ ʵ ʵ ʵ 71 52 7 5.5 KLM04 4 0.003
ʵ0.008 ʵ0.010 ʵ0.120
0 0 0
5 10 15 ʵ ʵ ʵ ʵ ʵ ʵ 118 90 12 9 KLM05 4 0.005
ʵ0.009 ʵ0.010 ʵ0.120
0 0 0
6 ʵ0.009 12 ʵ0.010 19 ʵ0.120 13.3 1.1 11.5 ʵ ʵ ʵ 130 107 13 11 KLM06 4 0.009
0 0
0 15 ʵ0.010 17 ʵ0.120 11.3 1.1 14.3 ʵ ʵ ʵ 116 94 12 9.5 KLM08 4 0.012
8 ʵ0.009 0 0
15 24 17.3 1.1 14.3 ʵ ʵ ʵ 234 187 24 19 KLM08-1 4 0.017
ʵ0.010 ʵ0.120
0 0 0
10 19 29 21.7 1.3 18 ʵ ʵ ʵ 435 297 45 30 KLM10 4 0.028
ʵ0.009 ʵ0.012 ʵ0.120
0 0 ʵ0
12 22 32 22.7 1.3 21 ʵ ʵ ʵ 480 380 49 39 KLM12 5 0.042
ʵ0.009 ʵ0.012 ʵ0.120
0 0 0
13 ʵ0.009 23 ʵ0.012 32 ʵ0.120 22.7 1.3 22 ʵ ʵ ʵ 540 455 55 47 KLM13 5 0.045
28 37 26.5 1.6 27 ʵ ʵ ʵ 875 670 89 68 KLM16 5 0.075
0 0 0
16 ʵ0.009 28 ʵ0.012 37 ʵ0.120 26.5 1.6 27 0.6 ʵ ʵ 875 670 89 68 KLM16S 5 0.075
28 37 26.5 1.6 27 ʵ 8.2 60˚ 875 670 89 68 KLM16P 4 0.062
32 42 30.3 1.6 30.5 ʵ ʵ ʵ 1 190 985 121 100 KLM20 6 0.10
0 0 0
20 32 42 30.3 1.6 30.5 0.6 ʵ ʵ 1 190 985 121 100 KLM20S 6 0.10
ʵ0.010 ʵ0.014 ʵ0.120
32 42 30.3 1.6 30.5 ʵ 8.6 50˚ 1 190 985 121 100 KLM20P 5 0.085
40 59 40.7 1.85 38 ʵ ʵ ʵ 2 640 2 340 269 239 KLM25 6 0.22
0 0 0
25 40 59 40.7 1.85 38 0.6 ʵ ʵ 2 640 2 340 269 239 KLM25S 6 0.22
ʵ0.010 ʵ0.014 ʵ0.120
40 59 40.7 1.85 38 ʵ 10.8 50˚ 2 640 2 340 269 239 KLM25P 5 0.19
45 64 44.2 1.85 43 ʵ ʵ ʵ 2 540 2 360 259 241 KLM30 6 0.26
0 0 0
30 45 64 44.2 1.85 43 0.6 ʵ ʵ 2 540 2 360 259 241 KLM30S 6 0.26
ʵ0.010 ʵ0.014 ʵ0.120
45 64 44.2 1.85 43 ʵ 13.0 50˚ 2 540 2 360 259 241 KLM30P 5 0.22
52 70 49.2 2.2 49 ʵ ʵ ʵ 3 400 2 970 345 305 KLM35 6 0.40
0 0 0
35 52 70 49.2 2.2 49 1.2 ʵ ʵ 3 400 2 970 345 305 KLM35S 6 0.40
ʵ0.012 ʵ0.017 ʵ0.120
52 70 49.2 2.2 49 ʵ 15.1 50˚ 3 400 2 970 345 305 KLM35P 5 0.34
